Four Spindles None Stop Turret Rewinder

Short Description:

Machine features1. Fully automatic 4-spindles turret type non-stop rewinding mac...


Product Detail

Product Tags

Machine features

1. Fully automatic 4-spindles turret type non-stop rewinding machine, the rate of achieving paper success is up to 100%. And it ensures that the tension stability of equipment in the production stage regardless of jog, speed increase, speed reduction, emergency, to realize the best condition of printing machine.

2. The turret type rewinding machine system adopts the world famous brand Bosch Rexroth,which provides intelligent production solutions. It adopts full servo closed-loop tension control and equips with a vibrating plate automatic paper-feeding tube mechanism, a discharge mechanism, to realize online non-stop rewinding.

3. The rewinder can be connected to rotary die cutting, slitting machines, flexographic printing machines and other equipment. It is equipped with a 1-inch 1.5-inch 3-inch quick release air-expansion shaft. The rewinding machine does not require manual mechanical adjustment when changing the size of different reels, its system automatically adjusts the size of the reel to reduce the labor force for intelligent production.

Machine speed

Max 90m/min when rewinding shaft is 25mm (1”)

Max 120m/min when rewinding shaft is 50-76mm (1.5”~3”)

3. The rewinder can be connected to rotary die cutting, slitting machines, flexographic printing machines and other equipment. It is equipped with a 1-inch 1.5-inch 3-inch quick release air-expansion shaft. The rewinding machine does not require manual mechanical adjustment when changing the size of different reels, its system automatically adjusts the size of the reel to reduce the labor force for intelligent production.

Technical parameters

Model size330mm
Max rewinding diameter350mm
Max width320mm
Min rewinding width40mm
Total power8KW
Power supply3PH+N+PE
Machine dimension1.45X3X1.7m
Machine weight2.0T
Air pressure0.8MPA
