Label Finisher, Printing, Die-cutting and Slitting in one machine

Short Description:

SpecificationModel(370)Model(470)Model(550)Max. Web Width370mm (14.57″)470mm(18....

Product Detail

Product Tags


Max. Web Width370mm (14.57″)470mm(18.50″)550mm(21.65″)
Max. Unwind Diameter800mm (31.50″)

Max. Flexo Printing Width350mm (13.78″)450mm(17.72″)530mm(20.87″)
Max. Die Cutting Width350mm (13.78″)450mm(17.72″)530mm(20.87″)
Full Rotary Max. Mechanical Speed120m/min

Semi-rotary Die Cutting Speed60m/min

Max. Flexo Printing Speed60m/min

Adhesive Die Cutting Precision Accuracy (cut 1st layer)±0.15mm

Die-cutting Precision Accuracy (cut totally)±0.25mm

Power Consumption19-21kW

Rating Voltage380V 50Hz

Machine Weight3200kgs
